  • EB-1800GZ Roller Hot Transfer Machine
Flat heat transfer machine
EB-1800GZ Roller Hot Transfer Machine
Model EB-1800GZ

Main Function and Technical Data

l   No need tailor made printing rollers, flexible for both small and big printing orders.

l   Fast Sample printing: It takes only 10 minutes to print out samples from artwork design.

l   Wide range of application: By thermal transfer printing, suitable for wide range of fabric including cotton.

l   Good print out effects: The printing outcome is perfectly good as flat surface heat transfer printing.

l   Equipped with pneumatic compression device, which gives flexibility to control the printing pressure.

l   The feed in and feed out mechanisms are firmly bonded with the machine which gives perfect balance and consistence fabric feeding.



Blanket Width:

1800mm

Transfer Speed:

0.5-4m/min

Design Power: 19.5kw
Drum Diameter: ¢420mm
Weight: 1600kg
Dimensions (L x W x H):

3000 x 2460 x 1420mm
